HS-V380

Health management all-in-one product introduction
HS-V380 intelligent whole-body health all-in-one machine is a high-end intelligent health physical examination device. The equipment has beautiful and atmospheric shape, high-quality accessories, accurate measurement, and adopts a new Windows system, fully automatic measurement, with voice broadcast, electronic display, optional face recognition function, and free connection to the regional standardized system, injecting new vitality into the construction of Internet + smart medical care. It is the best choice for major hospitals, physical examination centers, health huts, hospitals, elderly health centers, high-end clubs and other units.

Product features of health management machine
Ergonomic design, conforming to operating habits, pulley structure is convenient for mobile transportation. The main operating area adopts a dust-proof design, which is neat and beautiful and hygienic.
The measurement item is self-concealed and has a clean appearance, and is equipped with light green, healthy, energetic and progressive. At the same time, various color schemes specified by customers can be customized.
Full voice-guided self-service operation to swipe your ID card (C card) or enter your mobile phone number to build files and measure
Capacitive touch control operating screen is equipped with a high-definition camera with a thermal printer, and high-efficiency printing of physical examination reports supports data docking of third-party platforms.

Testing items
Complete testing projects, support function expansion covers basic public health projects, support interface docking data upload, project expansion, voice guidance, self-service one-stop physical examination, instant access to physical examination reports

Detection function
Height, weight, BMI (human body mass index), single electrocardiogram, infrared thermometer, blood pressure/pulse, blood oxygen saturation/pulse rate waist circumference, hip circumference, waist-hip ratio, blood sugar, uric acid, total cholesterol, Chinese medicine physique identification



Technical parameters

Product Model	HS-V380
Power Consumption	120W
Power Supply	AC 220V/50HZ
Network	RJ45/WIFI
Size	1.6m*0.6m*2.4m
Ultrasonic Height and Weight	Height range 70-205cm, accuracy ±0.5cm, using high-precision sensors; weight range 2.0-250KG, accuracy ±0.1KG, using precision balance beam sensors
Blood Oxygen Saturation	Measurement range: 70-100% (±2% under normal conditions, ±3% during exercise or weak perfusion, undefined below 70%)
Industrial Control Host	4-core CPU, 64G storage
Intelligent Touch Screen	24-inch high-definition screen
Printer	A4 laser printer
Infrared Thermometer	Measurement range: (in-body mode): 32.0℃-42.5℃, test accuracy: ±0.2℃
Electrocardiogram	Single guide
Body Fat	Fat content, water content, basal metabolic rate, body type judgment, bone mass, muscle rate, visceral fat, muscle mass, body fat mass, body water content
Waist Measurement	Three-dimensional measurement, accuracy 1mm
ID Card Reader	Complies with the general technical requirements for resident ID card readers, compatible with ISO14443 (TypeB) standard; adopts non-contact IC card technology, can be used to read information from the dedicated chip inside resident ID cards when connected to a computer or other devices

Health management machine application field
The HS-V380 intelligent high-end full-body health management machine is a new product independently developed by Huasheng Medical Technology. It can intelligently recognize faces (optional), has a high-end and atmospheric appearance, and is accurately measured. It is widely used in hospitals, schools, physical examination centers, troops, health huts, nursing homes, beauty and fitness clubs and other height measurement places.
